Cor-70 Industrial system with thermal break
A hinged window system that was conceived with the object of satisfying the needs of a determined market segment for an economical window system, simple but versatile with many features.
With a 70 mm frame depth and Euro Groove opening gearing, this innovation from the R&D Department has thermal transmission from only 0,8 W/m²K in order to adapt to distinct climatic severities and material demands on energy efficiency.
Its simplicity in fitting and reduced need for labour allows for a more industrialised manufacture resulting with time and cost savings at the end.
It features a straight style in both sash and bead.
A glazing capacity of up to 65.5 mm that allows the use of energy efficient glazing and compositions with large thicknesses and affords this system excellent accoustic and thermal features

Technical Data

Accoustic insulation

Maximum glazing: 55 mm.

Maximum accoustic insulation Rw=44 dB

Transmittance

Uw from 0,8 (W/m²K)
Please consult typology, dimensions and glass

Opening possibilities

Open In:
Practicable, turn-tilt, parallel tilt, hinged.

Open Out:

Practicable, projecting-sliding.

Apertura #1 Apertura #2 Apertura #4 Apertura #5 Apertura #6 Apertura #16 Apertura #18
Sections / Profile thickness

SECTIONS

· Frame – 70 mm.

· Sash – 78 mm.

PROFILE THICKNESS

Window 1,5 mm.

Balcony 1,7 mm.

Polyamide strip length from 32 to 35 mm.

Maximum dimensions / Maximum weight

MAXIMUM DIMENSIONS

Width(L)= 1.500 mm.

Height(H)= 2.600 mm.

*Single sash window, turn-tilt

Maximum weight/sash 120 Kg.

Please consult regarding maximum weight

and dimensions for other opening types

Categories achieved at test centre

Air permeability (EN 12207:2000):

CLASS 4

Water tightness (EN 12208:2000):

CLASS E1200

Wind resistance (EN 12210:2000):

CLASS C5

Reference test 1,23x1,48 m., 2 sashes.

Burglary resistance (EN 1627:2011):
RC2 grade (WK2)
Reference test window 2,52 x 1,47 m. 1 sash with EVO SECURITY fittings.

Finishes

Possibility of dual colour

Colour powder coating (RAL, mottled & rough)

Wood effect powder coating

Anti-bacterial powder coating

Anodized
