Equity Façade
A light curtain walling system with thermal insulation.
With a seen internal section of only 18 mm, both in the mullion as well as the transom, this new façade system presents a minimalist style and slenderness allowing a total entry of light to the interior of the building.
The mullion and transom profiles equalize its depth giving rise to a flush assembly that provides uniformity to the internal style of the façade.
The mullion and transom profiles equalize its depth giving rise to a flush assembly that provides uniformity to the internal style of the façade.
The glazing is achieved by fixing the glass using aluminium pressure covers, both in vertical as in horizontal, in such a way that the external view is 52 mm and internally is only 18 mm.
Technical Data
Glazing
Recommended glazing is an externally tempered pane.
Maximum recommended glazing is 40 mm
Transmittance
Ucw from 0,6 (W/m²K)
Please consult dimensions and glass
Please consult dimensions and glass
Opening possibilities
Hidden projecting
Sections/Profile thickness/Covers
INTERNAL SEEN SECTION
· Mullion – 18 mm.
· Transom – 18 mm.
Thermal breaking from 24 mm.
PROFILE THICKNESS
· Mullion – 2.6 mm.
· Transom – 2.6 mm.
COVERS
H shape cover, 34 mm deep.
Rectangular cover: 14, 19
& 100 mm deep
& 100 mm deep
Dimensions & weight max/min
MAXIMUM DIMENSIONS
Projecting opening
Max. Width (L)= 2.200 mm.
Max. Height(H)= 2.200 mm.
MAXIMUM WEIGHT
Projecting opening 140 Kg.
Fixed light 400 Kg.
Finishes
Colour powder coating (RAL, mottled & rough)
Wood effect powder coating
Anti-bacterial powder coating
Anodized
