6200 Sliding System

Technical Data

Accoustic insulation
Maximum glazing: 15 mm.

Maximum accoustic insulation Rw=35 dB
Transmittance
Uw from 3.2 (W/m²K),
Please consult typology, dimensions and glass
Opening possibilities
Sliding of  2, 3, 4 & 6 sashes.
Possibility of 3 rails
Possibility of double window
Apertura #13 Apertura #14 Apertura #15 Apertura #25
Sections / Profile thickness
SECTIONS
· Frame – 60 mm.
· Sash – 22 mm.

PROFILE THICKNESS
Window 1,25 mm.
Maximum dimensions / Maximum weight

MAXIMUM DIMENSIONS



Width(L)= 800 mm.

Height(H)=1.600 mm.

*window



Width(L)= 800 mm.

Height(H)=2.100 mm.

*balcony



Maximum weight/sash 80 Kg.



Please consult regarding maximum weight

 and dimensions for other opening types

Categories achieved at test centre
Air permeability (EN 12207:2000):
CLASS 3

Water tightness (EN 12208:2000):
CLASS 7A

Wind resistance (EN 12210:2000):
CLASS C3

Reference test 1,12 x 1,15 m., 2 sashes
Finishes

Colour powder coating (RAL, mottled & rough)

Wood effect powder coating

Anti-bacterial powder coating

Anodized
