Maximum  glazing: 48 mm.

Maximum accoustic insulation Rw=46 dB

Uw from 0.9 (W/m²K)

Please consult typology, dimensions and glass

Open In:

Practicable, turn-tilt, folding,
parallel tilt,hinged.

Open Out:

Practicable, projecting-sliding.

SECTIONS

· Frame – 60 mm.

· Sash – 70 mm.

PROFILE THICKNESS

Window 1,5 mm.

Door 1,7 mm.

Polyamide strip length: 25 mm.

MAXIMUM DIMENSIONS

Width(L)= 1.600 mm.

Height(H)= 2.800 mm.

*Single sash window, turn-tilt

Maximum weight/sash 150 Kg.

Please consult regarding maximum weight
and dimensions for other opening types

Air permeability (EN 12207:2000):

CLASS 4

Water tightness (EN 12208:2000):

CLASS E1200

Wind resistance (EN 12210:2000):

CLASS C5

Reference test 1,31 x 1,48 m., 2 sashes.

Possibility of dual colour

Colour powder coating (RAL, mottled & rough)

Wood effect powder coating

Anti-bacterial powder coating

Anodized
