2000 Perimetral Sliding System
A perimetral sliding system with the possibility of straight, bevelled and curved sashes.
Technical Data
Accoustic insulation
Maximum glazing: 17 mm.
Maximum accoustic insulation Rw=33 dB
Transmittance
Uw from 2.9 (W/m²K)
Please consult typology, dimensions and glass
Opening possibilities
Sliding of 2, 3, 4 & 6 sashes.
Possibility of 3 rails
Possibility of 1 rail
Sections / Profile thickness
SECTIONS
· Frame
- 40 mm. 1 rail
- 40, 45, 60 y 70 mm. 2 rails.- 40 mm. 1 rail
- 80 mm. 3 Rails.
· Sash(curve) – 27,5 mm.
· Sash (straight & chamfered) – 26 mm.
PROFILE THICKNESS
Window 1,5 mm.
Maximum dimensions / Maximum weight
MAXIMUM DIMENSIONS
Width(L)= 1.600 mm.
Height(H)= 2.600 mm.
Maximum weight/sash 100 Kg.
Please consult regarding maximum weight
and dimensions for other opening types
and dimensions for other opening types
Categories achieved at test centre
Air permeability (EN 12207:2000):
CLASS 3
Water tightness (EN 12208:2000):
CLASS 8A
Wind resistance (EN 12210:2000):
CLASS C5
Reference test 1,20 x 1,20 m., 2 sashes
Finishes
Colour powder coating (RAL, mottled & rough)
Wood effect powder coating
Anti-bacterial powder coating
Anodized
